Truepress Jet L350UV SAI Series UV Inkjet Label Presses
Extraordinary Speed and Quality Meets Unrivaled Flexibility
The Truepress Jet L350UV SAI series has been developed in response to the industry’s need for mixed, short-run printing for the high price and luxury segments. This new system enables significantly richer color expression as well as superior scalability, enabling it to meet a wide variety of market needs. “SAI” refers to its extremely Stable operation, highly Accurate color reproduction, and time-tested Integrated technologies.
Seven inks—C, M, Y, K, white, orange, and blue—ensure superior color reproduction while support for an extra printhead provides optimum future scalability. The system also features stable color reproduction, allowing for consistent printing time after time. These technologies provide a far wider range of color expression than was previously possible.
Truepress Jet L350UV SAI Advantages
- Cost of ownership
- Stability
- Cleaning/stitching control
- Structure
- Print resolution/minimum droplet size
- Speed/Productivity
Accurate
Stable
The Truepress Jet L350UV SAI delivers outstanding stability, enabling high-speed printing of up to 80 meters per minute. Built upon the most stable and successful platform of its kind, the Truepress Jet L350UV SAI series offers improved color reproduction as well as superior scalability, meeting and exceeding the demands of an even wider variety of market needs.Integrate
High scalability ensures flexibility in any work environment. The wide line-up provides printing companies with the optimal model for any current application while also allowing expanded functionality as operations grow.Comparison of printing times
UV Curing Inks For POD Label Systems
Highly versatile, low migration Truepress inks.
Truepress ink for L350 series are specially designed for the Truepress Jet L350 series of UV inkjet label systems. These innovative inks maximize the series’ already outstanding quality, stability and compatibility with a wide range of substrates.
PDFormstudio – Making Variable Printing Easy
Successful variable printing requires the right tools to create optimum files which will not impact the productivity of the press. Such tools need to be powerful, easy to use with an intuitive user interface, and capable of sorting files in the right order.
PDFormstudio is just the software tool you need!
Applications
Bottle Wrap
Bottle wraps on films with thicknesses down to 40 micron will show you the strong opacity of our whites.
Brand protection
The standard security features like Seal Vector, variable barcoding or numbering can also be used for brand protection.
Color-Logic metallic effects
For creating special effects onto metallic substrates, Equios can map a metallic separation to a white separation by using the Colour-Logic application. At the same time, it can also invert positive and negative images.
Pharmaceutical
In the pharmaceutical industry combatting counterfeiting of prescription drugs is essential. The range of security features that is included in the L350UV kit can strongly contribute to the safety of medicines within the supply chain.
Pouches and Sachets
Foodsafe pouches and sachets can also be produced in short run, with multiple sorts and sizes!
Labels
Screen delivers the UV inkjet technology that is highly prized by label printing companies looking for top-level productivity, smooth output of gradations, reproduction of wide CMYK colour gamut and single-pass versioning printing.
Literature
Download Brochure
Download Brochure (PDF)Specifications
Dimensions
| Product name | Truepress Jet L350UV SAI S | |
|---|---|---|
| Printing system | Piezo single-pass printing | |
| Resolution | 600×600 dpi | |
| Printing speed | 19.3 m2(207.8 ft2) / min at 60 m(196.8 ft)/min | |
| Printing size | Width: Maximum 322 mm (12.6″) Repeat length: 50.8 mm to 2438.4 mm(2″ to 96″) |
|
| Media size | Width: 100 mm to 350 mm(4″ to 13.7″) Roll diameter: Maximum 750 mm(29.5″) Weight: Maximum 120 kg(264 lb) |
|
| Media thickness | 0.04 to 0.35 mm(1.6 to 13.7 mil) | |
| Inks | Truepress inks for L350UV SAI Series Ink tank capacity: 8 liters per color Ink bottle capacity: 4 liters per color |
|
| Output configuration | CMYK + White <Standard specification> CMYK + White + Orange CMYK + White + Blue CMYK + White + Orange + Blue Orange and Blue inks can be added on-site. |
|
| Printheads | 4-step grayscale printheads Droplet size: Minimum 3 picoliter |
|
| Printer controller & RIP | EQUIOS for L350 SAI Series | |
| Main options | Web cleaner, Mark sensors, Corona unit, Splice detection sensors, Chiller, Dual UV lamps, Full color variable data processing*1, Reverse feed*1 MIS connection(CERM)*2 |
|
| Dimension(W × D × H)/Weight | Printer: 3,913 × 2,084 × 2300 mm (154.1″ × 82″ × 90.6″) / 2,860 kg(6,305 lb) | |
| Power requirements | Printer: Three phase, 380/400/415 V, 4 W, 50/60 Hz, 50 A*3 PC: Single phase, 100/240 V, 50/60 Hz, 600 W Earth leakage circuit breaker (200 mA sensed current) must be installed on the printer. |
|
| Operating environment | Required temperature relative humidity: 15 to 25°C (59 to 77°F)/40 to 70% [no condensation] Warrantied temperature and relative humidity: 18 to 24°C (64.4 to 75.2°F) / 40 to 70% [no condensation] Recommended elevation: less than 1,000 meters above sea level |
|
| Incidental utilities | Air-pressure utilities such as compressor Connection to exhaust duct |
|
*1. These options are under development.
*2. This option is not available in all regions.
*3. A boost transformer is required when installing in 200V area.
